Specs
| Product Specification | Industrial Skid-Mount |
|---|---|
| Fuel Capacity / Tank | 5.5 gallons – plastic tank with built-in fuel gauge |
| CFM Output | 4,680 |
| Frame Construction | All-steel, welded |
| Impeller Construction | 4-blade, 3/8″-thick blades, all-steel, welded |
| Impeller Mounting | Tapered locking hub |
| Impeller Diameter / Width | 20″ / 6.5″ |
| Blower Housing Construction | Removable back panel for easy impeller and wear plate access |
| Blower Housing Width | 7.5″ |
| Blower Housing Wear Plates | Standard: 1/4″-steel, replaceable |
| Hose Specifications | 120″ length, 12″-diameter intake hose, 0.045 black thermoplastic rubber, wire helix with wearstrip |
| Unit Mounting | 4″ steel skid risers |
| Discharge Tube | Clear thermoplastic, 8″ diameter |
| Throttle Control | Commercial-grade, all-steel mechanicals, plastic debris cover |
| Highway Ready | n/a |
| Axle | n/a |
| Tires | n/a |
| Trailer Width | n/a |
| Height | 75″ (without skid mount attached) |
| Weight | 675 lb |
| Warranty | 2-Year Commercial; 2-Year Non-Commercial; 90-Day Rental |
| MSRP | $7,999 |
