Specs
| Model | Description | MSRP |
|---|---|---|
| SW-32-14FS | 32″ Cutter Deck, 14 HP 481FS | $5,199 |
| SW-36A-14FS | 36″ Advantage Cutter Deck, 14 HP 481FS | $5,249 |
| SW-48V-14FS | 48″ Velocity Plus™ Cutter Deck, 14 HP 481FS | $5,599 |
| SW-52V-15FS | 52″ Velocity Plus™ Cutter Deck, 15 HP 541FS | $6,299 |
| * Limited availability. Contact your local Scag dealer for specific availability information. |
| Specification | SW Belt-Drive | |
|---|---|---|
| General | Total Fuel Capacity | 5.5 gallons |
| Drive Tires | 13″ x 5″-6″ (32″) 13″ x 6.5″-6″ (36″, 48″ and 52″) | |
| Caster Tires | 9″ x 3.5″ | |
| Seat | n/a | |
| Drive System | Drive System Type | Belt Drive with 5-Speed Peerless Transmission |
| Pumps | n/a | |
| Motors | n/a | |
| Forward Ground Speed | Up to 6 mph | |
| Reverse Ground Speed | 2 mph | |
| Parking Brake | Hand lever | |
| Deck | Cutting Widths | 32″, 36″, 48″ and 52″ |
| Type | Standard (32″) Advantage (36″) Velocity Plus™ (48″ and 52″) | |
| Cutting Height | 1.75″ to 4.5″ in .25″ increments | |
| Deck Lift | n/a | |
| Construction | Tri-plate cutter deck constructed of 3 steel plates totaling nearly 1/2″ of steel. Reinforcement plates at cutter deck spindles. 32″ model features dual-plate. | |
| Spindles | Cast-iron housing with tapered roller bearings. | |
| Blade Engagement | Ogura MA-GT-EXM3X (110ft lb) Adjustable air-gap for extended life. |
