Specs
Technical specifications
| Tractors Model | 2515H  | 2515R |
Engine manufacturer | TYM T1700N6 | TYM T1700N6 |
Engine power | 24 hp | 18 kW | 24 hp | 18 kW |
Rated engine speed | 2100 rpm | 2100 rpm |
Displacement | 104.5 cu. in. | 1714 cc | 104.5 cu. in. | 1714 cc |
No. of speeds | 3-Range | F12 x R12 |
Hitch lift capacity | 1500 kg | 3306 lb | 1500 kg | 3306 lb |
PTO rear | 540 rpm | 540 rpm |
Fuel tank | 7.1 gal | 27 L | 7.1 gal | 27 L |
Overall length with 3-point hitch | 120.9 in. | 3071 mm | 120.9 in. | 3071 mm |
Overall width | 56.3 in. | 1430 mm | 56.3 in. | 1430 mm |
Wheelbase | 65.7 in. | 1670 mm | 65.7 in. | 1670 mm |
Height to top of ROPS | 97.3 in. | 2471 mm | 97.3 in. | 2471 mm |
Min. ground clearance | 14.4 in. | 366 mm | 14.4 in. | 366 mm |
Weight with ROPS | 2969 lb | 1347 kg | 2989 lb | 1356 kg |
Weight with cab | - | - |
R1 Agricultural - Front | 8-16 | 8-16 |
R1 Agricultural - Rear | 12.4-24 | 12.4-24 |
| Download | Technical Brochure | Technical Brochure |
