Specs
Technical specifications
| Tractors Model | 2610  | 2400 | T224  |
Engine manufacturer | TYM T1100N2 | TYM T1100N2 | Yanmar 3TNV74F |
Engine power | 24 hp | 17.9 kW | 24 hp | 17.9 kW | 21.5 hp | 16 kW |
Rated engine speed | 2850 rpm | 2850 rpm | 3200 rpm |
Displacement | 71.7 cu. in. | 1175 cc | 71.7 cu. in. | 1175 cc | 60.6 cu. in. | 993 cc |
No. of speeds | 3-Range | 2400R: F6 x R2 2400H: 2-Range | 2 Range |
Hitch lift capacity | 1499 lb | 680 kg | 1499 lb | 680 kg | 1100 lb | 499 kg |
PTO rear | 540/1000 rpm | 540/1000 rpm | 540 rpm |
Fuel tank | 6.0 gal | 23 L | 6.0 gal | 23 L | 6.6 gal | 25 L |
Overall length with 3-point hitch | 122.9 in. | 3122 mm | 120.3 in. | 3055 mm | 94.2 in. | 2394 mm |
Overall width | 53.8 in. | 1369 mm | 44.2 in. | 1122.7 mm | 44.5 in. | 1130 mm |
Wheelbase | 65.7 in. | 1670 mm | 59.1 in. | 1502 mm | 53.1 in. | 1350 mm |
Height to top of ROPS | 91.5 in. | 2328 mm | 87.3 in. | 2219 mm | 86.6 in. | 2200 mm |
Min. ground clearance | 15.1 in. | 382 mm | 12.1 in. | 307.3 mm | 8.3 in. | 210 mm |
Weight with ROPS | 2106 lb | 956 kg | 1792 lb | 813 kg | 1472 lb | 668 kg |
Weight with cab | - | - | - |
R1 Agricultural - Front | 7-16 | 6-12 | BAR F 16x6.50-8 |
R1 Agricultural - Rear | 11.2-20 | 9.5-16 | BAR R 24x12.00-12 |
| Download | Technical Brochure | Technical Brochure | Technical Brochure |
