Specs
Technical specifications
Tractors Model | 3620H | 3620R |
Engine manufacturer | TYM T1700N2 | TYM T1700N2 |
Engine power | 35 hp | 26.0 kW | 35 hp | 26.0 kW |
Rated engine speed | 2500 rpm | 2500 rpm |
Displacement | 104.5 cu. in. | 1714 cc | 104.5 cu. in. | 1714 cc |
No. of speeds | 4-Range | F16 x R16 |
Hitch lift capacity | 1500 lb | 3306 kg | 1500 lb | 3306 kg |
PTO rear | 540/750 rpm | 540/750 rpm |
Fuel tank | 11.8 gal | 45 L | 11.8 gal | 45 L |
Overall length with 3-point hitch | 127.4 in. | 3236 mm | 127.4 in. | 3236 mm |
Overall width | 64.9 in. | 1650 mm | 64.9 in. | 1650 mm |
Wheelbase | 71.1 in. | 1806 mm | 71.1 in. | 1806 mm |
Height to top of ROPS | 98.4 in. | 1200 mm | 98.4 in. | 1200 mm |
Min. ground clearance | 15.5 in. | 394 mm | 15.5 in. | 394 mm |
Weight with ROPS | 3754 lb | 1703 kg | 3754 lb | 1703 kg |
Weight with cab | - | - |
R1 Agricultural - Front | 9.5-16 | 9.5-16 |
R1 Agricultural - Rear | 12.4-28 | 12.4-28 |
Download | Technical Brochure | Technical Brochure |
