Specs
Technical specifications
| Tractors Model | 4815H  | 4815R |
Engine manufacturer | TYM T2300N2 | TYM T2300N2 |
Engine power | 48 hp | 35.8 kW | 48 hp | 35.8 kW |
Rated engine speed | 2600 rpm | 2600 rpm |
Displacement | 139.5 cu. in. | 2287 cc | 139.5 cu. in. | 2287 cc |
No. of speeds | 3-Range | 12F / 12R |
Hitch lift capacity | 3306 lb | 1500 kg | 3306 lb | 1500 kg |
PTO rear | 540 rpm | 540 rpm |
Fuel tank | 7.1 gal | 27 L | 7.1 gal | 27 L |
Overall length with 3-point hitch | 120.9 in. | 3071 mm | 120.9 in. | 3071 mm |
Overall width | 56.3 in. | 1430 mm | 56.3 in. | 1430 mm |
Wheelbase | 65.7 in. | 1670 mm | 65.7 in. | 1670 mm |
Height to top of ROPS | 97.3 in. | 2471 mm | 97.3 in. | 2471 mm |
Min. ground clearance | 14.4 in. | 366 mm | 14.4 in. | 366 mm |
Weight with ROPS | 3278 lb | 1487 kg | 3278 lb | 1487 kg |
Weight with cab | - | - |
R1 Agricultural - Front | 8-16 | 8-16 |
R1 Agricultural - Rear | 12.4-24 | 12.4-24 |
| Download | Technical Brochure | Technical Brochure |
