Specs
Technical specifications
| Tractors Model | T264  | T254  | T224  |
Engine manufacturer | TYM T1100N2 | Yanmar 3TNV80F | Yanmar 3TNV74F |
Engine power | 24 hp | 18 kW | 23.9 hp | 17.8 kW | 21.5 hp | 16 kW |
Rated engine speed | 2800 rpm | 3000 rpm | 3200 rpm |
Displacement | 71.7 cu. in. | 1175 cc | 77.3 cu. in. | 1267 cc | 60.6 cu. in. | 993 cc |
No. of speeds | Infinite 2-Range | Infinite 2-Range | 2 Range |
Hitch lift capacity | 1534 lb | 696 kg | 1214 lb | 551 kg | 1100 lb | 499 kg |
PTO rear | 540 rpm | 540 rpm | 540 rpm |
Fuel tank | 6.6 gal | 25 L | 5.8 gal | 22 L | 6.6 gal | 25 L |
Overall length with 3-point hitch | 107.8 in. | 2740 mm | 100.5 in. | 2553 mm | 94.2 in. | 2394 mm |
Overall width | 52.8 in. | 1342 mm | 45.8 in. | 1164 mm | 44.5 in. | 1130 mm |
Wheelbase | 58.3 in. | 1480 mm | 57.5 in. | 1460 mm | 53.1 in. | 1350 mm |
Height to top of ROPS | 89.8 in. | 2280 mm | 91.3 in. | 2320 mm | 86.6 in. | 2200 mm |
Min. ground clearance | 7.7 in. | 196 mm | 9.4 in. | 240 mm | 8.3 in. | 210 mm |
Weight with ROPS | 1881 lb | 853 kg | 1638 lb | 743 kg | 1472 lb | 668 kg |
Weight with cab | - | - | - |
R3 Turf - Front | Turf Master 23x8.50-12 NHS TL 4PR | Turf Master 20x8.00-10 NHS TL 4PR | Turf Master 16x7.50-8 NHS TL 4PR |
R3 Turf - Rear | Multi-Trac CS 33x12.50-16.5 NHS TL 4PR | Multi-Trac CS 29x12.50-15 NHS TL 4PR | Turf Master 24x12.00-12 NHS TL 4PR |
