Specs
Technical Specification
| Tractors Model | T494C  | T494  | T574 |
Engine manufacturer | TYM T2300N2 | TYM T2300N2 | TYM T2300T2 |
Engine power | 48.3 hp | 36 kW | 48.3 hp | 36 kW | 55 hp | 41 kW |
Rated engine speed | 2600 rpm | 2600 rpm | 2600 rpm |
No. of speeds | F8 x R8 | F8 x R8 | F8 x R8 |
Hitch lift capacity | 3822 lb | 1733 kg | 3822 lb | 1733 kg | 3822 lb | 1733 kg |
PTO rear | 540 rpm | 540 rpm | 540 rpm |
Fuel tank | 17.0 gal | 60 L | 17.0 gal | 60 L | 17.0 gal | 60 L |
Overall length with 3-point hitch | 141.3 in. | 3590 mm | 141.3 in. | 3590 mm | 141.3 in. | 3590 mm |
Overall width | 63.8 in. | 1620 mm | 63.8 in. | 1620 mm | 63.8 in. | 1620 mm |
Wheelbase | 76.2 in. | 1935 mm | 76.2 in. | 1935 mm | 76.2 in. | 1935 mm |
Min. ground clearance | 13.8 in. | 350 mm | 13.8 in. | 350 mm | 13.8 in. | 350 mm |
Weight with cab | 4198 lb | 1904 kg | - | - |
Weight with ROPS | - | 3871 lb | 1756 kg | 3887 lb | 1763 kg |
R1 Agricultural - Front | Farm Specialist 9.5-16 NHS TL 6PR | Farm Specialist 9.5-16 NHS TL 6PR | Farm Specialist 9.5-16 NHS TL 6PR |
R1 Agricultural - Rear | Farm Specialist 13.6-26 NHS TL 6PR | Farm Specialist 13.6-26 NHS TL 6PR | Farm Specialist 13.6-26 NHS TL 6PR |
| Download | Technical Brochure | Technical Brochure | Technical Brochure |
