Specs
Technical Specification
| Tractors Model | T5075  | T654  | T1104  |
Engine manufacturer | Deutz TCD 2.9L | Deutz TCD2.9L4 | Doosan Infracore D34P |
Engine power | 74.3 hp | 55.4 kW | 67 hp | 50 kW | 111 hp | 82 kW |
Rated engine speed | 2200 rpm | 2200 rpm | 2300 rpm |
Displacement | 178.5 cu. in. | 2925 cc | 177 cu. in. | 2900 cc | 208 cu. in. | 3409 cc |
No. of speeds | F16 x R16 (Creep interlock) | F24 x R24 | F32 x R32 |
Hitch lift capacity | 5515 lb | 2320 kg | 4270 lb | 1937 kg | 6860 lb | 3112 kg |
PTO rear | 540/750 rpm | 540/750/1000 rpm | 540/750/1000 rpm |
Fuel tank | 23.7 gal | 90 L | 18.5 gal | 70 L | 29.1 (DEF 5.3) gal | 110 (DEF 20) L |
Overall length with 3-point hitch | 168.1 in. | 4269 mm | 155.6 in. | 3952 mm | 167.3 in. | 4250 mm |
Overall width | 92.3 in. | 2345 mm | 72.4 in. | 1840 mm | 86 in. | 2185 mm |
Wheelbase | 86.1 in. | 2188 mm | 84.6 in. | 2150 mm | 90.6 in. | 2300 mm |
Height to top of cabin | 104.9 in. | 2664 mm | 100.2 in. | 2545 mm | mm in. | 2718 107 |
Min. ground clearance | 18.4 in. | 467 mm | 17.1 in. | 435 mm | 18.3 in. | 465 mm |
Weight with cab | 6316.2 lb | 2865 kg | 5555 lb | 2520 kg | 8929 lb | 4050 kg |
R1 Agricultural - Front | 280/85R24 | FSTR 9.5 R20 TL | FSTR 380/85R24 TL (14.9R24) |
R1 Agricultural - Rear | 420/85R30 | FSTR 380/85R28 TL (14.9R28) | FSTR 460/85R34 TL (18.4R34) |
