Specs
Technical Specification
| Tractors Model | T554C  | T554  | T654  |
Engine manufacturer | Yanmar 4TNV86CT | Yanmar 4TNV86CT | Deutz TCD2.9L4 |
Engine power | 55.9 hp | 41.1 kW | 55.9 hp | 41.1 kW | 67 hp | 50 kW |
Rated engine speed | 2800 rpm | 2800 rpm | 2200 rpm |
Displacement | 127.6 cu. in. | 2091 cc | 127.6 cu. in. | 2091 cc | 177 cu. in. | 2900 cc |
No. of speeds | F16 x R16 | F16 x R16 | F24 x R24 |
Hitch lift capacity | 3314 lb | 1503 kg | 3314 lb | 1503 kg | 4270 lb | 1937 kg |
PTO rear | 540 rpm | 540 rpm | 540/750/1000 rpm |
Fuel tank | 17.0 gal | 60 L | 17.0 gal | 60 L | 18.5 gal | 70 L |
Overall length with 3-point hitch | 141.3 in. | 3590 mm | 141.3 in. | 3590 mm | 155.6 in. | 3952 mm |
Wheelbase | 76.2 in. | 1935 mm | 76.2 in. | 1935 mm | 84.6 in. | 2150 mm |
Height to top of ROPS | 102.1 in. | 2594 mm | 102.1 in. | 2594 mm | - |
Min. ground clearance | 13.8 in. | 350 mm | 13.8 in. | 350 mm | 17.1 in. | 435 mm |
Weight with ROPS | 1730 lb | 3814 kg | 3814 lb | 1730 kg | - |
R1 Agricultural - Front | Farm Specialist 9.5-16 NHS TL 6PR | Farm Specialist 9.5-16 NHS TL 6PR | FSTR 9.5 R20 TL |
R1 Agricultural - Rear | Farm Specialist 13.6-26 NHS TL 6PR | Farm Specialist 13.6-26 NHS TL 6PR | FSTR 380/85R28 TL (14.9R28) |
| Download | Technical Brochure | Technical Brochure | Technical Brochure |
