Specs
Bale Size
- Bale Diameter 36 in - 72 in (91.4 cm - 182.9 cm)
- Bale Width 47 in 119.4 cm
- Maximum bale weight 2400 lbs 1088.6 kg
Dimensions and Weights
- Length standard 164 in 416.6 cm
- Length with net 184 in 467.4 cm
- Length with ramp 206 in 523.2 cm
- Height 121 in 307.3 cm
- Width with standard tires 101 in 256.5 cm
- Width with optional tires 115 in 292.1 cm
- Tires Standard - 14L-16.1; Optional - 21.5L-16.1 flotation tire
- Weight fully optioned 7280 lbs 3302.2 kg
Bale Forming Chamber
- Drive Roller Size 5.5 in (14 cm)
- Idler roller size 3.5 in (8.9 cm), 4.8 in (12.1 cm)
- Start Roller Size 5.3 in 13.3 cm
- Belt Type Premium mini rough top
- Number of Belts 6
- Width of Belt 6.8 in 17.3 cm
- Length of belt (long) 563.5 in 1431.3 cm
- Length of belt (short) 557 in 1414.8 cm
- Type of Lace Alligator rivet
- Silage kit Optional
Drive System
- Driveline Standard: 540 rpm, standard lube, friction clutch; Optional: 1000 rpm, standard lube, automatic clutch
- Torque protection pickup Radial pin clutch
- Roller chains Single 60 and 80
- Bearing and Sprocket Configuration Hex drive shafts and bearings
Tractor Requirements
- PTO horsepower minimum 70 hp 52.2 kw
- PTO horsepower recommended 90 hp 67.1 kw
Pickup
- Pickup type Camless wide
- Width tooth to tooth 70.5 in 179.1 cm
- Width on outside flair 73.8 in 187.5 cm
- Tooth Bars 5
- Number of Teeth (70) double rubber-mounted
- Teeth spacing 2.83 in (7.2 cm)
- Stripper bands Steel
- Flotation Gauge wheels 4.8 - 16 HD semi-pneumatic with spring assist
- Pickup Lift Hydraulic
- 3-year pickup warranty Standard
Control system
- Control system type Atlas Pro™ control system
- Display 7 in (17.8 cm) color touch screen
- Field Statistics 50 fields with names
- Field statistics download USB
- Bale shape indicators Standard
- Moisture Standard - up to 27%
- Bales per hour Standard
- Auto eject Optional
Density
- Bale density adjustments Standard through control system monitor
- Density readings Digital gauge
- Cylinder size 2.5 in (6.4 cm)
Bale tie system
- Twine system Optional
- Netwrap system Optional
- Net gauge via control system Standard
- Net tension control via control system
- Netlift system Optional
- Extra roll storage Standard
Features
- Bale ramp Hydraulic
- Auto Lube greasing system Optional
- Grease bank Standard
- Right-hand door Standard
- LED maintenance lights Optional
- Fire extinguisher, safety chain Optional
