Specs
Dimensions and Weights
- Transport Width - ends up 10.8 ft 3.3 m
- Transport width - standard 10.8 ft 3.3 m
- Transport Length 6.3 ft 1.9 m
- Cutting Width 10.9 ft 3.3 m
- Working Height 60 in 152.4 cm
- Working Width 13 ft 4 m
- Working Length 6.3 ft 1.9 m
- Cutter bar lift height clearance 20 in 50.8 cm
- Total Weight 1980 lbs 898.1 kg
- Total weight - with rubber roller conditioner 2720 lbs 1233.8 kg
- Total weight - with flail conditioner 2450 lbs 1111.3 kg
- Suspension Hydraulic
- Torque Protection Friction and over-running clutch
Tractor Requirements
- Tongue/hitch Front 3-point, CAT II
- Drive PTO 1000
- PTO horsepower recommended 80 hp (60 kW)
- PTO horsepower recommended - with rubber roller conditioner 110 hp (81 kW)
- PTO horsepower recommended - with flail conditioner 110 hp (81 kW)
- Hydraulic Type 1 double-acting
- Hydraulic Pressure 2030 psi 140 bar
Cutter bar
- Cutter bar type Gear bed cutter bar
- Cut height 1.6 in - 2.8 in (4 cm - 7 cm)
- Number of Discs 8
- Disc Speed 3000 rpm
- Number of Blades 16
- Angle Adjustment Top-link on 3-point
- Quick Clip® blade retention system Quick blade change
- Quick-Changeâ„¢ shear ring 4 brass pins shear protection
- 3-year limited cutter bar warranty Standard
Features
- Optional swath formation Without conditioner: swath wheels; With conditioner: swathboards
- Skid Shoes Standard wear skids, optional topping skids
Roller Conditioner
- Type Intermeshing rubber rollers
- Conditioner Drive (3) V-belt
- Conditioner Width 105 in 266.7 cm
- Roller Diameter 8.9 in 22.6 cm
- Roller Speed 1000 rpm
- Windrow width minimum 44 in 111.8 cm
- Windrow width maximum 91 in 231.1 cm
- Topping high cut kit Optional topping skids
Flail conditioner
- Type Steel V-tine
- Conditioner Drive Cogged belt
- Conditioner Width 105 in 266.7 cm
- Working Diameter 19 in 48.3 cm
- Tine Speed Low 750 rpm
- Tine Speed High 1000 rpm
- Windrow width minimum 75 in 190.5 cm
- Windrow width maximum 106 in 269.2 cm
- Topping high cut kit Optional topping skids
