Specs

• Dimensions and Weights

  • Raking width minimum 12.5 ft 3.8 m
  • Raking width maximum 14 ft 4.3 m
  • Windrow width minimum 28 in 71.1 cm
  • Windrow width maximum 47 in 119.4 cm
  • Transport Width 6.8 ft 2.1 m
  • Transport Length 16.4 ft 5 m
  • Transport Height 3.9 ft 1.2 m
  • Total Weight 1570 lbs 712.1 kg
  • Tongue/hitch weight 820 lbs 371.9 kg
  • Transport tire size 18x8.50-8 x (4)
  • Rotor tire size 18x8.50-8 x (4)
  • Flotation 2x walking tandem axle
  • Drive PTO

• Raking components

  • Tooth diameter .3 in .8 cm
  • Rotor diameter 11 ft 3.4 m
  • Number of tine arms 12
  • Number of double tines per arm 4
  • Windrow width adjustment Manual
  • Windrow position Left side
  • Rotor lift Hydraulic

• Tractor Requirements

  • PTO horsepower minimum 27 hp 20.1 kw
  • Recommended PTO horsepower 40 hp 29.8 kw
  • Hydraulic Type 1 single-acting
  • Hydraulic Pressure 2000 psi 137.9 bar
  • Hydraulic flow rate 5 gpm 18.9 L/min
  • PTO speed 540 rpm
  • Recommended PTO speed 350 rpm - 450 rpm
  • Hitch Drawbar

• Features

  • Highway Lights Standard
  • Safety Chain Optional
