Specs

• Dimensions and Weights

  • Raking width minimum 24 ft 7.3 m
  • Raking width maximum 27 ft 8.2 m
  • Windrow width minimum 45 in 114.3 cm
  • Windrow width maximum 84 in 213.4 cm
  • Transport Width 9.8 ft 3 m
  • Transport Length 19 ft 5.8 m
  • Transport Height 13.1 ft 4 m
  • Total Weight 4600 lbs 2086.5 kg
  • Tongue/hitch weight 2000 lbs 907.2 kg
  • Transport tire size 380/55-17, steering axle
  • Rotor tire size 16x6.50-8
  • Flotation 3x walking tandem axle under each rotor
  • Drive PTO

• Raking components

  • Tooth diameter .3 in .8 cm
  • Rotor diameter 11.6 ft 3.5 m
  • Number of tine arms 26
  • Number of double tines per arm 4
  • Single-side raking Optional electric/hydraulic separate rotor lift
  • Windrow width adjustment Hydraulic
  • Windrow position Center
  • Rotor lift Hydraulic

• Tractor Requirements

  • PTO horsepower minimum 55 hp 41 kw
  • Recommended PTO horsepower 75 hp 55.9 kw
  • Hydraulic Type 1 single-acting, 1 double-acting
  • Hydraulic Pressure 2000 psi 137.9 bar
  • Hydraulic flow rate 6 gpm 22.7 L/min
  • PTO speed 540 rpm
  • Recommended PTO speed 400 rpm - 500 rpm
  • Hitch 2-point

• Features

  • Highway Lights Standard
