Specs

• Dimensions and Weights

  • Tedding width 10 ft 3 m
  • Transport Height 8.8 ft 2.7 m
  • Transport Width 11.6 ft 3.5 m
  • Transport Length 10.4 ft 3.2 m
  • Total Weight 670 lbs 303.9 kg
  • Tongue Weight 88 lbs 39.9 kg
  • Tire size 16 x 6.5-8
  • Basket tilt and adjustment Manual crank
  • Number of Baskets 2
  • Tine Arms per Basket 6
  • Type of Tine Straight tine
  • Torque protection driveline Radial pin clutch

• Tractor Requirements

  • PTO Horsepower Requirements 15 hp 11.2 kw
  • Hitch Drawbar clevis connection
  • Drive PTO 540 rpm

• Features

  • SMV Sign Standard
