Specs

• Dimensions and Weights

  • Tedding width 25 ft 7.6 m
  • Transport Height 9.8 ft 3 m
  • Transport Width 9.8 ft 3 m
  • Transport Length 15.3 ft 4.7 m
  • Total Weight 3200 lbs 1451.5 kg
  • Tongue Weight 900 lbs 408.2 kg
  • Tire size 18.5 x 8.5-8
  • Transport tire size 11L-15 8
  • Basket tilt and adjustment Hydraulic, adjustable by changing wheel frame/main frame mount
  • Number of Baskets 6
  • Tine Arms per Basket 6
  • Type of Tine Hook tine
  • Torque protection driveline Radial pin clutch

• Tractor Requirements

  • PTO Horsepower Requirements 47 hp 35 kw
  • Hydraulic requirements 1 double-acting with floating position
  • Hydraulic pressure minimum 2000 psi 137.9 bar
  • Hitch Drawbar clevis connection
  • Drive PTO 540 rpm

• Features

  • SMV Sign Standard
