Specs

• Dimensions and Weights

  • Tedding width 33.5 ft 10.2 m
  • Transport Height 9.5 ft 2.9 m
  • Transport Width 9.8 ft 3 m
  • Transport Length 15.3 ft 4.6 m
  • Total Weight 5200 lbs 2358.7 kg
  • Tongue Weight 1260 lbs 571.5 kg
  • Tire size 18.5 x 8.5-8
  • Transport tire size 31 x 13.5-15
  • Basket tilt and adjustment Hydraulic, adjustable by changing wheel frame/main frame mount
  • Number of Baskets 8
  • Tine Arms per Basket 7
  • Type of Tine Hook tine
  • Torque protection driveline Radial pin clutch

• Tractor Requirements

  • PTO Horsepower Requirements 60 hp 44.7 kw
  • Hydraulic requirements 2 double-acting with floating position
  • Hydraulic pressure minimum 2100 psi 144.8 bar
  • Hitch Drawbar clevis connection
  • Drive PTO 540 rpm

• Features

  • SMV Sign Standard
