Specs

• Dimensions and Weights

  • Tedding width 48.6 ft 14.8 m
  • Transport Height 8.2 ft 2.5 m
  • Transport Width 9.8 ft 3 m
  • Transport Length 20.5 ft 6.2 m
  • Total Weight 7430 lbs 3370.2 kg
  • Tongue Weight 2580 lbs 1170.3 kg
  • Tire size 16x6.50-8 (outer), 16x9.50-8 (center)
  • Transport tire size 380/55-17
  • Basket tilt and adjustment Standard hydraulic adjustment
  • Number of Baskets 14
  • Tine Arms per Basket 6
  • Type of Tine Hook tine
  • Torque protection driveline Cut-out clutch and over-running clutch

• Tractor Requirements

  • PTO Horsepower Requirements 100 hp 74.6 kw
  • Hydraulic requirements 2 double-acting
  • Hydraulic pressure minimum 2000 psi 137.9 bar
  • Hydraulic flow rate 5 gpm 18.9 L/min
  • Hitch Drawbar clevis connection
  • Drive PTO 540 rpm

• Features

  • SMV Sign Standard
  • Highway lighting Standard
  • Safety Chain Standard
