Specs
Dimensions and Weights
- Transport Height 76 in 193 cm
- Transport width - standard 9.1 ft 2.8 m
- Transport width with flotation tires 9.8 ft 3 m
- Transport Length 25.2 ft 7.7 m
- Cutting Width 20.8 ft 6.3 m
- Working Height 76 in 193 cm
- Working Width 27.1 ft 8.3 m
- Working Length 19.8 ft 6 m
- Total Weight 6660 lbs 3020.9 kg
- Tongue Weight 1940 lbs 880 kg
- Suspension Hydraulic
- Torque Protection Driveline: friction disc clutch
- Tires Standard 31x13.5-15; Optional 480/45x17 flotation tire
Tractor Requirements
- Tongue/hitch 2-point quick hitch with swivel gearbox, category II or III N
- Drive PTO 1000 rpm
- PTO horsepower recommended 105 hp 78.3 kw
- Hydraulic Type 3 double-acting (2 double-acting with optional kit)
- Hydraulic Pressure 1850 psi 127.6 bar
- Hydraulic flow rate 6 gpm 22.7 L/min
Cutter bar
- Cutter bar type Q3®
- Cut height 1 in - 3 in (2.5 cm - 7.6 cm)
- Number of Discs 14
- Disc Diameter 23 in 58.4 cm
- Disc Speed 2690 rpm
- Number of Blades 28
- Angle Adjustment Hydraulic pitch control
- Quick Clip® blade retention system Standard
- Quick-Changeâ„¢ shear ring Standard
- Curtain material 1400 g/m2 polyester woven material with flexible PVC covering
- 3-year limited cutter bar warranty Standard
Features
- Optional swath formation Optional swathwheel
- Skid Shoes Standard modular independent skid shoes; Optional topping wear skids
- Highway Lights Standard
