Specs

• Dimensions and Weights

  • Raking width minimum 22 ft 6.7 m
  • Raking width maximum 28 ft 8.5 m
  • Windrow width minimum 36 in 91.4 cm
  • Windrow width maximum 72 in 182.9 cm
  • Transport Width 10.5 ft 3.2 m
  • Transport Length 31.1 ft 9.5 m
  • Transport Height 6.3 ft 1.9 m
  • Total Weight 5040 lbs 2286.1 kg
  • Tongue Weight 1300 lbs 589.7 kg
  • Transport tire size 11L-15
  • Flotation Hydraulic
  • Drive Hydraulic

• Raking components

  • Number of Rake Wheels 14
  • Rake wheel diameter 55 in 139.7 cm
  • Teeth per wheel 40
  • Tooth diameter .3 in .8 cm
  • Rake wheel wind discs Optional

• Tractor Requirements

  • PTO horsepower minimum 40 hp 29.8 kw
  • Hydraulic Type 3 double-acting
  • Hydraulic Pressure 1800 psi 124.1 bar
  • Hydraulic flow rate 5 gpm 18.9 L/min

• Features

  • Highway Lights Standard
  • Safety Chain Optional
  • Center splitter Optional
