Specs

• Dimensions and Weights

  • Raking width maximum 25 ft 7.6 m
  • Windrow width minimum 36 in 91.4 cm
  • Windrow width maximum 72 in 182.9 cm
  • Transport Width 8.3 ft 2.5 m
  • Transport Length 24.8 ft 7.6 m
  • Transport Height 6.4 ft 2 m
  • Total Weight 3820 lbs 1732.7 kg
  • Tongue Weight 1367 lbs 620.1 kg
  • Transport tire size 205/75-R15
  • Flotation Steep spring on individual rake wheel

• Raking components

  • Number of Rake Wheels 12
  • Rake wheel diameter 60 in 152.4 cm
  • Teeth per wheel 40
  • Tooth diameter .3 in .8 cm
  • Rake wheel wind discs Optional
  • Single-side raking Optional

• Tractor Requirements

  • PTO horsepower minimum 30 hp 22.4 kw
  • Hydraulic Type 2 double-acting
  • Hydraulic Pressure 1800 psi 124.1 bar
  • Hydraulic flow rate 5 gpm 18.9 L/min

• Features

  • Highway Lights Standard
  • Safety Chain Optional
  • Center splitter Optional
