Specs

• Dimensions and Weights

  • Loading height - standard 109 in 276.9 cm
  • Machine weight - standard 13780 lbs 6250.5 kg
  • Maximum net load 19000 lbs 8618.3 kg
  • Total length 273 in 693.4 cm
  • Transport width - 50-in folding conveyor extension 113 in 287 cm
  • Working width - 50-in folding conveyor extension 130 in 330.2 cm
  • Tires (retread) Standard 425/65R-22.5; Optional 255/70R-22.5 dual

• Tub and screws

  • Capacity 600 cu ft 17 cu m
  • Number of screws 2
  • Number of knives per screw 5
  • Tub wall thickness 1/4 in (6.4 mm)
  • Tub wall material AR200
  • Floor thickness 3/4 in (19.1 mm)
  • Screw flighting thickness 5/8 in (15.9 mm)
  • Screw flighting material AR200

• Discharge System

  • Discharge style Front conveyor
  • Discharge Direction Left or right
  • Folding conveyor extension length 25 in/40 in/50 in (64 cm/100 cm/130 cm)
  • Bi-directional conveyor length 101 in/110 in/119 in (257 cm/280 cm/302 cm) OR 101 in (257 cm) hydraulic shift
  • Rear discharge door Optional

• Tractor Requirements

  • Minimum PTO horsepower 140 hp (100 kW)
  • Recommended PTO horsepower 150 hp 111.9 kw

• Drive System

  • Driveline 1,000 rpm, CV
  • Two-speed gearbox Optional
  • Torque Protection Shear bolt
  • Screw rpm 39 (1-speed); 39/26 (2-speed)

• Scale system

  • Scale display Digi-Star EZ2810-BT
  • Number of weigh bars 4
  • Bluetooth connectivity Standard
